Horizontal plunger metering pump

Horizontal plunger metering pump
Our company currently has eight machine bases, J1, J2, J3, J4, J5, J6, J7 and J8, and more than 280 specifications of horizontal plunger metering pumps. All eight machine bases are N-shaped shaft structures. The power of the motor drives the connecting rod, crosshead and plunger to reciprocate through the worm gear and worm, so as to achieve the purpose of driving the suction valve and the discharge valve to convey the medium. The flow regulation is to change the eccentricity of the connecting rod through the axial movement of the N-shaped shaft to achieve the purpose of changing the plunger stroke and adjusting the flow. The stroke adjustment of the metering pump is divided into three forms: manual, electric and pneumatic for users to choose. The stroke can be adjusted steplessly within the range of 0 to 100%, and the pump can be adjusted in both the stopped and moving states. Among them, the electric adjustment of the stroke can realize the requirements of remote and automatic control. The speed of the pump can be adjusted with a frequency converter or a speed regulating motor to achieve dual adjustment of the stroke and speed to meet the requirements of different process flows. And the flow-through material can provide metal materials or non-metal materials according to the different use requirements of users.
